PRE-START

• Park Brake ON

• Circuit Breakers CHECK

• Master Switch KEY ENGINE

• Choke if cold engine ON

• Fuel Pump ON→PRESSURE

• Fuel Pump OFF

• Throttle MIN + ½ TURN

• Ignition 1 & 2 ON

• Propeller Area CHECK

• “Clear Prop” ANNOUNCE

• Starter ENGAGE

AFTER START

• Oil Pressure RISING/GREEN

• Choke OFF

• Throttle 2000 RPM

• Avionics ON

SYMBOLS

Δ Difference

| OR

& AND

≤ Less than or equal to

≥ Greater than or equal to

RUN-UP

• Oil Temp ≥50°C

• Park Brake ON

• Choke OFF

• Throttle 3600 RPM

• Ignition 1 CHECK ≤125 RPM

• Ignition 2 CHECK ≤125 RPM

• Ignition 1/2 Δ ≤50 RPM

• Carburettor Heat ON→OFF

• Idle CHECK ≥1250 RPM

• Throttle 2000 RPM

PRE TAKE-OFF

• Trim SET TKOF

• Mixture CHOKE OFF

• Prop Pitch FULL FINE

• Flight CTRL FREE&CORRECT

• Flaps SET TKOF

• Fuel ON&SUFF QTY

• Instruments CHECK

• Switches AS REQ

• Hatches & Harnesses CHECK

• T/O Safety/DEP/TEM BRIEF

HOLDING READY

• Lights STROBE ON

• Camera XPDR 3000 ALT

• Action READY, REQ CLR

PRE LANDING

• Brakes PRESSURE&OFF

• Undercarriage DOWN&LOCKED

• Mixture CHOKE OFF

• Fuel ON&SUFF QTY

• Instruments CHECK

• Switches AS REQ

• Hatches & Harnesses CHECK

AFTER LANDING

• Lights OFF

• Flaps & Trim SET TKOF

SHUT DOWN

• Park Brake ON

• Flaps & Trim SET TKOF

• Throttle MIN RPM

• Avionics OFF

• Ignition 1 OFF

...pause 2 seconds

• Ignition 2 OFF

• Master Switch KEY OFF

AFTER SHUT DOWN

• MR if last FLT of day CLOSE

• Hobbs/Tach REC BOOK

• Hobbs/Tach REC OFFICE

• Aircraft SECURE

EMERG FORCED LDG

• Aviate, Navigate, Comm.

• Best Glide 65KIAS

• Troubleshoot F.A.S.T.

• Fuel pump ON

• Fuel selectors 3xON

• Air CARB HEAT ON

• Switches IGNITION 2xON

• Switches MASTER ON

• Throttle CYCLE

• Turn over ENGINE START

• Field SELECT

• Wind

• Obstacles

• Size

• Shape

• Surface

• Slope

• Sun

• Shoots

• Surroundings/Buildings

• Communicate MAYDAY

• Passenger BRIEF

• Aircraft SECURE

STALL ENTRY

• Clearing Turn AS REQ

• Height RECOVER ≥2000 AGL

• Aircraft CONFIG, TRIM

• Security HARNESS, OBJECTS

• Engine OPS NORMAL, P/T

• Location UNPOPUL, FLD AVBL

• Lookout TRAFFIC

• Listen CHECK FREQ

SPEEDS

• Vne 124KIAS

• Va 95KIAS

• Vfe 81KIAS

• Vs0 36KIAS

• Vs1 43KIAS

• Vx 60KIAS

• Vy 65KIAS

• Best Glide 65KIAS

• Max wind (RWY HDG) 25KT

• Max crosswind 15KT

• Max tailwind 6KT

FREQUENCIES

• YBAF ATIS 120.90MHz

• YBAF SMC 119.90MHz

• YBAF TWR (NORTH) 123.60MHz

• YBAF TWR (SOUTH) 118.10MHz

• YBAF CTAF 118.10MHz

• YBAF AWIS 128.40MHz

• YBAF PAL 118.10MHz

• BN CEN Train. 125.70MHz

• BN CEN 45NM N. 129.00MHz

• BN CEN 14NM S. 119.50MHz

• YHEC CTAF 119.00MHz

• Southport CTAF 119.00MHz

• YAMB ATIS 123.30MHz

• GEN Air Distress 121.50MHz

ENGINE

• Model Rotax 912ULS

• Max RPM (5 mins) 5800RPM

• Max RPM (cont.) 5500RPM

• Block Fuel Burn 20L/hr

• Min VFR Reserve 45min

• Fuel 95RON|AVGAS100LL

• Min Oil Temp 50°C

• Max Oil QTY 2.6L

• Min Oil QTY 2.1L

24-4844

• Total Fuel Capacity 85.1L

• Total Fuel Capacity 61.3kg

• Total Usable Fuel 83L

• Total Usable Fuel 59.8kg

• Basic Empty Weight 288.5kg

• Empty Arm 244.8mm

• Empty Arm 18.83%

• Permitted CG min. 259.08mm

• Permitted CG min. 20%

• Permitted CG max. 363.22mm

• Permitted CG max. 28%

• Max Take-Off Weight 560kg

• Min Crew Weight 55kg

• Max Baggage Weight 20kg

• Max LF (no flaps) +4G

• Min LF (no flaps) -2G

• Max LF (flaps) +2G

• Min LF (flaps) 0G

• Max Angle of Bank 60°

• Max endurance 6 hours

• Max range 534NM

• Service ceiling 14760ft

• Propeller FITI ECO ⌀1580mm

24-5350

• Total Fuel Capacity 85.0L

• Total Fuel Capacity 61.2kg

• Total Usable Fuel 83L

• Total Usable Fuel 59.8kg

• Basic Empty Weight 303.5kg

• Empty Arm 266.0mm

• Empty Arm 20.46%

• Permitted CG min. 259.08mm

• Permitted CG min. 20%

• Permitted CG max. 363.22mm

• Permitted CG max. 28%

• Max Take-Off Weight 560kg

• Min Crew Weight 54.9kg

• Max Baggage Weight 20kg

• Max LF (no flaps) +4G

• Min LF (no flaps) -2G

• Max LF (flaps) +2G

• Min LF (flaps) 0G

• Max Angle of Bank 60°

• Max endurance 6 hours

• Max range 534NM

• Service ceiling 14760ft

• Propeller FITI ECO ⌀1580mm

24-8881

• Total Fuel Capacity 86.0L

• Total Fuel Capacity 61.9kg

• Total Usable Fuel 85L

• Total Usable Fuel 61.2kg

• Basic Empty Weight 303.8kg

• Empty Arm 304.0mm

• Empty Arm 24.18%

• Permitted CG min. 260mm

• Permitted CG min. 20%

• Permitted CG max. 442mm

• Permitted CG max. 34%

• Max Take-Off Weight 560kg

• Min Crew Weight 54kg

• Max Baggage Weight 20kg

• Max LF (no flaps) +4G

• Min LF (no flaps) -2G

• Max LF (flaps) +2G

• Min LF (flaps) 0G

• Max Angle of Bank 60°

• Max endurance 6 hours

• Max range 534NM

• Service ceiling 14760ft

• Propeller FITI ECO ⌀1580mm
